工業折疊機

產品詳情

主要特點：

1.采用大屏幕點陣液晶顯示及智能化控制系統，并且有良好的中英文人機對話界面；

2.在電腦監控下完成5次折疊，縱折和橫折次數可按織布幅度、厚度自由編程；

3.采用高智能化的紅外線檢測系統，取消了傳統的機械脈沖計數裝置；

4.具有雙通道折疊功能，可雙倍提高小型布草的熨平折疊能力，降低能耗；

5.運轉速度調節范圍大，能與各種相應的熨平機匹配；

6.具有自診斷功能，完善的安全保護系統，檢測點自保養功能，

7.電腦版采用繼電器輸出，無需中間繼電器，減少了故障點，維修檢測方便；

8.各控制組件均采用直流24V低壓組件，安全可靠，便于直接維修；

9.各控制閥均采用氣動控制，動作迅速可靠，對周圍環境無污染；

10.本設備多處裝有安全開關，使用安全可靠。

Main Features：

1.Adopt large lattice LCD screem and intelligentized controlling system,also has good English and Chinese Language man-machine conversation interface.

2.It finishes five times folding in the guard of computer,vertical folding and horizontal,folding’s times could be programmed according to the fabric’s width and thickness.

3.Adopt intelligentized infrared testing system, abrogate traditional machanical pulse counting device.

4.Possess double channels folding function,could double improve machinical pulse counting device.

5.With wide range speed-adjusting,which can match with each ironing machine.

6. Prossess self-diagnosis function,perfect safety protection system and self-maintaining function.

7.Relay output is used for the computer panel,medial relay is not necessary,reduced malfunctions and make maintain and inspecting convenient.

8.Each control or module adopts DC 24V low voltage module,safe and reliable,easily to be maintained directly.

9.Each valve adopts pneumatic controlling,which makes actions quick and safe,and no pollution to the surrounding environment.

10.Safe switches are installed for many parts to make sure the safe and reliable operation.
